SKU: ATZ AVS158 Category:

ATZ AVS158

$220.00


8 Port VGA splitter with audio, 500 Mhz, w/POWER


Share it:

ATZ AVS158 is a VGA splitter 1×8 with audio. It distributes the input of the VGA signal and stereo audio signal into the eight identical outputs simultaneously. This product has the ability of buffering and amplifying. Each amplifier splitter’s output can achieve long distance transmission of VGA signal of more than 15 meters.

This VGA Splitter offers solutions for monitors or projectors retail and show site, and Projector factory, noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.

Features:

  • Easy to Use: Install in seconds, no need of setting.
  • Connects VGA source to eight VGA displays at the time.
  • Connects stereo audio source to eight audio receivers at the time.
  • Supports highest video resolution up to 1920 x 1200 and 1080p
  • Supports highest video Amplifier Bandwidth to 500MHz
Weight 1 kg
Dimensions 25 x 25 x 10 cm
  • Input Video Signal: 1.2V p-p
  • Maximum Single LinkRange: 1920×1200, 1080p
  • Vertical Frequency Range: 30 to 170Hz
  • Video Amplifier Bandwide: 500Mhz
  • Input Connector: VGA 15 pin Male
  • Output Connector: VGA 15 pin Female
  • Operating Temperature: 0 Degree Celsius to 70 Degree Celsius
  • Operating Humidity: -10 to 85% RH (no condensation)
  • Storage Temperature: -10 Degree Celsius to 80 Degree Celsius
  • Storage Humidity: 5% to 90% RH (no condensation)
  • External Power Supply: 5V DC@2A
  • Power Consumption: 5w Max
  • Regulatory Approval: FCC, CE, UL
