Description
Features:
- Support HDMI signal source of PlayStation 4, Xbox One and Xbox 360 game play in brilliant 1080p@60HZ with advanced H.264 encoding.
- Recording with one-click, easy to use, no need any set up. Just click “RECORD” button to record your game play and re-click to stop recording.
- Support NTFS/FAT32 format.
- Support USB 2.0 Host.
- Automatically split the video up to 2GB per file.
- Support record video format of MPEG-4 and audio format of RCA L/R 3.5mm microphone input.
- Support by pass mode or downscaling 1080P/1080i to 720P.
Additional information
| Weight | 0.55 kg |
|---|---|
| Dimensions | 26 x 15 x 5.8 cm |
| Operating Temperature Range | -5 to +35℃(+23 to +95℉) |
| Operating Humidity Range | 5 to 90%RH (No Condensation) |
| Output Video Format | MPEG-4 |
| encoder | H.264 |
| Input resolution | 720×480(60HZ);720×576(50HZ);1280X720P(50HZ/60HZ) |
| 1920X1080i(50HZ/60HZ); | |
| 1920X1080P(24HZ/25HZ/30HZ/50HZ/60HZ) | |
| Capture resolution | 720×480(60HZ);720×576(50HZ);1280X720P(50HZ/60HZ) |
| 1920X1080i(50HZ/60HZ); | |
| 1920X1080P(24HZ/25HZ/30HZ) | |
| Support Audio Format | LPCM |
| Bandwidth | 2.25Gbps |
| USB Version | 2.0 |
| Power consumption | 3watts(Maximum) |
| Dimension (L×W×H) | 102.2×70.1×27.1mm |
| Net Weight | 220g(Pcs) |
