Description

Cat6A S/FTP Stranded LSZH cable 26AWG 7/0.16 Bare Copper cable, OD:6.0 (305M) Grey

Category: Cat 6A
Structure: S/FTP (PiMF)
Application: Patch cord raw cable
Construction: 26AWG 7/0.16mm (+/-0.008mm)
Material: Bare Stranded Copper
Material: Foam-PE
Outside Diameter: 1.04 +/- 0.05mm
Color : Pair 1: Orange, Orange-White, Pair 2: Blue, Blue-White, Pair 3: Green, Green-White, Pair 4: Brown, Brown-White
Pin definition: TIA 568B
Pair Shielding Material: Aluminum foil
Outer Shield Material: 80*0.12 AL-MG wire braiding
Jacket Material: LSZH
Outer diameter: 6.0mm +/- 0.2mm
Average thickness: 0.6mm
Color: Grey
Marking Color: Black
Marking Jacket: ATZ Patch Cord Category 6A S/FTP 500MHz 26AWG/4PRS LSZH VERIFIED TO ANSI/TIA/EIA 568.2-D & ISO/IEC 11801 RoHS atz.com.sg

ATZ STPCAT6A.305M-STR.GY
