HDMI2.0 Repeater, HDR,18Gbps, 4K@60Hz, YUV 4:4:4 w/ power supply
Description
This super mini HDMI repeater is designed to regenerate the incoming HDMI signal by decoding and re-encoding it to a new standard HDMI signal and extend the transmission range without degradation.
Features:
- Supports HDMI 2.0 and backwards compatible with earlier versions.
- Serial data rate up to 6.0 Gbps, capable of supporting ultra-high resolution 4K/2K @ 60 Hz format.
- Supports HDCP 2.2
- Supports 3D transmission.
- Supports 30m at 4K/60Hz,RGB 4:4:4 resolution, both input and output transmission distance up to 15m using HDMI 2.0 AWG24 cable.
- Supports 40m at 4K/30Hz,RGB 4:4:4 or 4K/60Hz RGB 4:2:0 resolution, both input and output up to 20m using HDMI 2.0 AWG24 cable.
- Supports 60m 1080P/60Hz resolution, both input and output transmission distance can up to 30m using HDMI 2.0 AWG24 cable.
- Audio and video lossless transmission without any delay.
- Simple installation.
| Input | 1x HDMI |
| Output | 1x HDMI |
| Maximum Range | 4K@60Hz, YUV 4:4:4, 25m (15m to source + 10m to display)
4K@30Hz, 40m (25m to source + 15m to display) 1080P@60Hz, 50m (30m to source + 20m to display)
|
| Maximum Resolution | 4K@60Hz, 4:4:4 |
| Data transfer speed rate | 18Gbps(Maximum) |
| HDMI Compliance | Up to HDMI2.0 |
| HDCP Compliance | Up to HDCP2.2 |
| Operating Temperature Range | -5 to +55℃(+23 to +131℉) |
| Operating Humidity Range | 5 to 90%RH (No Condensation) |
| Support Video Color Format | Deep color 36bit |
| Support Audio Format | DTS-HD/true-HD/LPCM7.1/AC3/DTS/DSD |
| Power consumption | 1watts(Maximum) |
| External Power Source (optional) | 5V 150mA on DC receptacle |
| Dimension (L×W×H) | 52x45x21mm |
| Net Weight | 128g |
